Chiller Features:
• Shell and tube evaporator and air cooled condenser, high efficient thread red copper tube (material change on request).
• Siemens PLC control, LCD touch screen interface, easy operation, Standard design charged.
• R22, CFC free R407c, R134a for option.
• 380V-415V-480V/50/60HZ, 3PH for standard design. Chiller unit can be supplied according to diffierent requirements.
• Unit adopts Germany BITZER or Taiwan HANBELL brand semi-hermetic screw compressor. The latest 5 to 6 patented screw rotor profile with excellent efficiency for energy saving purpose
• Adjustable infinite or closely stepped capacity control, features energy efficient, stable and quiet running.
• Most advanced patented highest precision manufacturing process.
• Built-in full intelligent monitoring and protection including thermal motor temperature monitoring, phase sequence monitoring, manual reset lock-out, oil temperature sensor.
Microcomputer Control System:
• Industrial PLC centralized control combined with compressor capacity control system, precisely monitor.
• Integrated protection for low temperature, high/low pressure, anti-freezing, phase missing, anti-phase, overload, motor over temperature, oil differential, flow switch, start up latency.
• Optional operation language, menu leading, unit running state easy to adjust.
• Easy Installation, Reliable Running.
Specification
Item | Specification / Supplier | ||
Cooling capacity | Model | AYD-710A | |
ton/h | 100 | ||
Power input | kw | 128.2 | |
Current | A | 230 | |
Temp Outlet (℃) | 7 | ||
Power Supply | 380V-3N-50HZ | ||
refrigerant control | Expansion valve | ||
Refrigeration circle | one | ||
refrigerant | R134A | ||
Dimension（mm）L×W×H | 6000*2100*2200 | ||
Compressor | Style | Semi-hermetic screw type | |
Quantity（set） | 1 | ||
Compressor Power(kw) | 115 | ||
Start Way | 0-25%-50%-75%-100% | ||
Condenser
| Style | Fin | |
Air Volume（m3/h） | 144000 | ||
Fan Power(kw) | 13.2 | ||
Evaporator | Style | Shell and Tube / 1set | |
Cold water flow（m3/h） | 65 | ||
Pipe size（DN） | 125 | ||
Unit Weight（kg） | 3800 | ||
Food and Beverages - Microbreweries, confectionary, bakeries, distilleries, wineries, bottling, corbonation, vegetable, meat and fish processing, etc.
Pharma and chemical - Jacketed vessels cooling, condenser cooling, PUF mixers, Laboratories applications, x ray spectrometers,
paint cooling, packing machine, anodizing, plating, liquid nitrogen plant, etc
Other industries- plastic industry, electronics industry, electroplating industry, machinery industry, construction industry, laser industry, ultrasonic/ultrasound industry, numerical control processing industry, ship manufacturing industry, steel and iron manufacturing industry, discharge industry, shoe making industry, leather dry cleaning industry etc.
