ANYDA is well acknowledged as one of the leading manufacturers of inverter glycol water chiller in daily chemical industry in China. All of the products for sale are made in our professional plant. Should you're interested in it, please be free to get the high-tech equipment with competitive price from us.
In the daily chemical industry, low temperature glycol chillers are critical for process cooling, ensuring product quality, improving production efficiency, and enabling the creation of heat-sensitive formulations. They typically provide chilled glycol water between 0°C and -20°C (or lower for specialized processes).
Typically 0°C to -20°C for most applications. Ordinary water will freeze, so a coolant like a glycol-water mixture is required.
Here we have a customer use a glycol chiller in soap manufacturing, mainly for:
1.Rapid Cooling & Solidification: After the saponification process and extrusion from a vacuum plodder, the soap mass is hot and soft. Low-temperature chillers rapidly cool the soap to harden it instantly, allowing it to be cut and stamped without deformation.
2.Mold Release & Shaping: Rapid cooling ensures the soap releases cleanly from molds, maintaining precise dimensions, smooth surfaces, and consistent shapes while significantly increasing production line speed.
3.Preventing Crystallization Issues: Controlled cooling prevents unwanted crystal formations (like "soap scum" or "sweating") within the bar, resulting in a more stable and aesthetically pleasing final product.
Now the customer want to save energy, they want to adopt a inverter chiller,which is a variable frequency drive (VFD) chiller.
A VFD chiller adjusts its motor speed to precisely match the cooling demand.This can reduce energy consumption by 30% to 50% (or even more in partial load conditions) because the chiller never runs at full power when it isn't needed. Lower energy use directly translates to lower electricity bills.While the upfront cost is higher, the lower operating costs often provide a full return on investment (payback) within 1–3 years.Then we choose the model under 60hz when it is fully operating.
|
Item |
Specification / Supplier |
||
|
Cooling capacity |
Model |
AYD-40WS |
|
|
kw/h |
44.8 |
||
|
ton/hr |
12.7 |
||
|
Power input |
kw |
38.1 |
|
|
Current |
A |
65.2 |
|
|
Power Supply |
380V-3N-50HZ |
||
|
Temp Outlet (℃) |
-25 |
||
|
refrigerant control |
Expansion valve |
||
|
Refrigeration circle |
1 |
||
|
refrigerant |
R404A |
||
|
Dimension(mm)L*W*H |
3500*1500*1800 |
||
|
Compressor |
style |
Screw |
|
|
Qty |
1 |
||
|
Compressor power(kw) |
38.1 |
||
|
Condenser |
Style |
Shell and Tubes/1set |
|
|
Chilled water flow(m3/h) |
19 |
||
|
Pipe size(") |
3 |
||
|
Evaporator |
Style |
Shell and Tubes/1set |
|
|
Cold water flow(m3/h) |
7.7 |
||
|
Pipe size(") |
1-1/2 |
||
|
Water Pump(kw) |
4(6m3/hr, 8bar) |
||
|
Pump Qty(pcs) |
1 |
||
|
Water Tank(L) |
500 |
||
|
Protector Device |
1,Phase protector 2,Flow protector 3,High/low voltage protector 4,Coil overheat protector 5,Anti-freeze protector |
||
|
Unit Weight(kg) |
1280 |
||
|
Main Parts Brand |
|||
|
Compressor |
Hanbell |
||
|
Electronic |
LS / Chnt |
||
|
Expansion Valve |
Sanhua |
||
|
Electrical Control |
Punp |
||
Remark:
1. The cooling capacity is based on condensing temperature 40C, inlet/outlet temperature -20/-25C.
2. The specs are under 60hz.(inverter range 30~ 60hz.
RFQ:
1.Where is the glycol water chiller used for?
beverage cooling, milk cooling, brewery cooling, ice rink cooling, ice cream cooling and so on.
2.Which info you need to know to confirm a model?
heat load, like flow rate, cool from which temperature down to which temperature.
3.Which refrigerant usually adopt?
R404A and R449A.
4.If I need customized configuration, could you satisfy?
Yes, anti-corrosive area, vsd driven, split system like remote air condenser, remote control and anything you asked we will give you our solutions.
