50 Ton 80 Hp 200 Kw Air Cooled Water Chiller Machine With Competitive Price is one of the chiller models that cools normal temperature water through a chiller compressor to a certain temperature to enhance cooling of the mold or machine. As a stand-alone machine, the heat sink is a built-in fan. There are three interconnected systems: refrigerant circulation system, water circulation system, and electrical control system.
Parameter
Item | Specifications | |
Cooling Capacity | Model | AYD-200AS |
kw/h | 205.6 | |
Power Input | kw | 70 |
Outlet Temp | degree | 7 |
Power Supply | 400V-3N-50HZ | |
Refrigerant | R407C | |
Dimension(L*W*H) | mm | 3180*1900*2060 |
Compressor | Type | semi-hermetic screw |
Power(kw) | 60 | |
Condenser | Type | Finned |
Fan Power(kw) | 6.8 | |
Air Volume(m3/h) | 84000 | |
Evaporator | Type | Shell and Tubes |
Pipe Size(") | 3 | |
Flow(m3/h) | 35.36 | |
Protector Device | 1.Phase protector | |
Features
50 Ton 80Hp Air Cooled Water Chiller Machine With Competitive Price unit compressors use scroll-type fully enclosed compressors and electronic control components, equipped with condensers and evaporators made of heat-exchange efficient high-quality copper tubes.
It is equipped with various safety protection devices, stable performance, low noise, long service life and simple operation. It adopts liquid crystal display man-machine interface, which is easy and convenient to operate, and the operation status is clear at a glance.
The model has a single compressor or multiple compressor combination refrigeration system. The compressor can be alternately operated according to the load, and the operating hours of each compressor are balanced to save energy and prolong the service life of the chiller.
