Product Feature
1,Newest imported compressors and high-efficient condenser,evaporator, strong cooling ability, silent and energy-saving, micro-computer comprehensive control, easy operation(optional).
2,Adopting newest stainless-steel open style water tank, convenient to clean and maintain.
3,Current overloaded protection, Low & High pressure protection and electronic time delaying protection device and other abnormal condition indication system.
4,Screen liquid crystal display of chill water outlet and inlet with temperature setting (Options available)
5,Elegant appearance through industrial design.
Specs Table:
Item | Specification / Supplier | |
Cooling capacity | Model | AYD-30A |
kw | 72 | |
Power input | kw | 27.3 |
Temp Outlet | ℃ | 7 |
Power Supply | 380V-3N-50HZ | |
refrigerant control | Expansion valve | |
Refrigeration circle | three | |
refrigerant | R407C | |
Dimension | (mm)L*W*H | 2760*900*1750 |
Compressor | Style | Scroll |
Quantity | pcs | 3 |
Compressor Power | kw | 21.73 |
Condenser | Style | Fin type |
Qty | pcs | 3 |
Power | kw | 2.55 |
Air Volume | m3/h | 31500 |
Evaporator | Style | Shell and Tubes |
Cold water flow | m3/h | 15 |
Pipe size | DN | 65 |
Pump Power | kw | 3(22m3/h,2.7bar) |
Tank | L | 250 |
Protector Device | 1.Phase protector 2.Fan overload protector 3.High/low voltage protector 4.overheat protector 5.Anti-freeze protector | |
Unit Weight | kg | 1080 |
Operating Weight | kg | 1300 |
Main Parts | ||
Compressor | Sanyo | |
Condenser | Anyda | |
Evaporator | Jindian | |
Electronic | LS / Carlo | |
Expansion Valve | Sanhua | |
Electrical control | Xinrong | |
Remarks: the cooling capacity calculated based on evaporator temp 2C, condensing temp 45C.
